MW Series Ultrafine Grinding Mill

MW Series Ultrafine Grinding Mill is a new superfine powder (325-2500 mesh) production equipment developed through accumulating years of experience in grinding mill production, absorbing advanced machine manufacturing technology, and undergoing many years of tests and improvements.

Product Features: Ultrafine powder, wide applications, excellent environmental effect
Input Size: 0-20mm
Capacity: 0.5-25TPH
Material: Limestone, calcite, dolomite, petroleum coal, gypsum, barite, marble, talc, coal powder, etc.

Advantages of MW Series Ultrafine Grinding Mill:
1. Higher Yielding, Lower Energy Consumption;
2. Adjustable Fineness Between 325-2500meshes;
3. No Rolling Bearing & Screw in Grinding Chamber;
4. Dust Removal by Pulse Collector Makes Operation More Eco-friendly.

Working Principle of MW Series Ultrafine Grinding Mill:
Materials are sent to the grinding mill evenly and they would fall onto the dispersing plate firstly. When the grinding mill runs, dozens of grinding rollers start to rotate and roll. Under the action of centrifugal force, materials on the dispersing plate are then thrown to the rim and drop to the grinding chamber. In the circuit, materials would be squeezed and ground. After being ground several times, materials are blown into the powder selector by airflow. Under the action of the impeller of powder selector, materials which fail to meet fineness would be sent back to grinding chamber to get another grinding while qualified powders would be collected by cyclone powder collector and discharged from the bottom as finished products. Some remaining powders would be collected by impulse dust remover and they may stick to the surface of filler-bag. So, next, high-pressure airflow controlled by the impulse valve blows the filler-bag to make it swell and shake violently. This sudden shake can help kick off materials on the filler-bag and collect them as finished products. After filtering, the airflow would be discharged to the air.

Specifications – Technical Data

Model Main diameter(mm) Quantity of grinding ring(layer) Quantity of roller(piece) Main shaft speed(rpm) Maximum feed size(mm) Output fineness(μm/mesh) Capacity(t/h) Dimension(m) Power(kw)
MW880 800 3 21 230-240 ≤20 5-47 0.4-4.5 13.9*4*6.2 145-165
MW980 930 3-4 24-32 200-220 ≤20 5-47 0.6-6.5 14.7*4.8*7.2 185-204
MW1080 1035 3 27 180-200 ≤20 5-47 0.7-7 18*4.6*8.6 263
MW1080L 1035 4 34 180-200 ≤20 5-47 1-8.5 18*4.6*8.6 263-290
MW1285 1300 4 40-44 135-155 ≤20 5-47 1.5-12 14*9*10.25 380-430
MW1688 1680 4 30-40 120-130 ≤20 100-9 3.8-30 26.3*7.5*11.9 600-700
